China Harmonic Drive Gear with Hollow Shaft

Basic Info.

Model NO.	HST-14-50-III
Installation	90 Degree
Layout	Coaxial
Gear Shape	Cylindrical Gear
Step	Single-Step
Type	Gear Reducer
Series	Hst-III
One Hundred	Fifty/Eighty/One Hundred/One Hundred
Model	Fourteen/Seventeen/Twenty/Twenty-Five/Thirty-Two
Transport Package	Foam+Carton
Specification	HST-14-50-III
Trademark	Homwing
Origin	Shenzhen, Guangdong, China
HS Code	84834090
Production Capacity	30000/Year

Product Description

Product Description:

1.Flexspline is a hollow flanging standard cylinder structure. 2.There is a large-diameter hollow shaft hole in the middle of the cam of the wave generator. The internal design of the reducer has a support bearing. 3.It has a fully sealed structure and is easy to install. It is very suitable for the occasions where the wire needs to be threaded from the center of the reducer.

Advantages:

The first:High precision,high torque

The second:dedicated technical personnel can be on-the-go to provide design solutions

The third:Factory direct sales fine workmanship durable quality assurance

The fourth:Product quality issues have a one-year warranty time, can be returned for replacement or repair

Company profile:

Strength factory:

HST-III Parameter:

HSG Parameter:

Exhibition:


Application case:

established in 2014, is committed to the R & D plant of high-precision transmission components. At present, the annual production capacity can reach 45000 sets of harmonic reducers. We firmly believe in quality first. All links from raw materials to finished products are strictly supervised and controlled, which provides a solid foundation for product quality. Our products are sold all over the country and abroad. The harmonic reducer and other high-precision transmission components were independently developed by the company. Our company spends 20% of its sales every year on the research and development of new technologies in the industry. There are 5 people in R & D. Our advantage is as below: 1.7 years of marketing experience 2. 5-person R & D team to provide you with technical support 3. It is sold at home and abroad and exported to Turkey and Ireland 4. The product quality is guaranteed with a one-year warranty 5. Products can be customized

Our plant has an entire campus The number of workshops is around 300 Whether it's from the production of raw materials and the procurement of raw materials to the inspection of finished products, we're doing it ourselves. There is a complete production system

Model	Speed ratio	Enter the rated torque at 2000r/min		Allowed peak torque at start stop		The allowable maximum of the average load torque		Maximum torque is allowed in an instant		Allow the maximum speed to be entered	Average input speed is allowed	Back gap	design life
		NM	kgfm	NM	kgfm	NM	kgfm	NM	kgfm	r / min	r / min	Arc sec	Hour
14	50	6.2	0.6	20.7	2.1	7.9	0.7	40.3	4.1	7000	3000	≤30	10000
	80	9	0.9	27	2.7	12.7	1.3	54.1	5.5
	100	9	0.9	32	3.3	12.7	1.3	62.1	6.3
17	50	18.4	1.9	39	4	29.9	3	80.5	8.2	6500	3000	≤30	15000
	80	25.3	2.6	49.5	5	31	3.2	100.1	10.2
	100	27.6	2.8	62	6.3	45	4.6	124.2	12.7
20	50	28.8	2.9	64.4	6.6	39	4	112.7	11.5	5600	3000	≤30	15000
	80	39.1	4	85	8.8	54	5.5	146.1	14.9
	100	46	4.7	94.3	9.6	56	5.8	169.1	17.2
	120	46	4.7	100	10.2	56	5.8	169.1	17.2
	160	46	4.7	100	10.2	56	5.8	169.1	17.2
25	50	44.9	4.6	113	11.5	63	6.5	213.9	21.8	4800	3000	≤30	15000
	80	72.5	7.4	158	16.1	100	10.2	293.3	29.9
	100	77.1	7.9	181	18.4	124	12.7	326.6	33.3
	120	77.1	7.9	192	19.6	124	12.7	349.6	35.6
32	50	87.4	8.9	248	25.3	124	12.7	439	44.8	4000	3000	≤30	15000
	80	135.7	13.8	350	35.6	192	19.6	653	66.6
	100	157.6	16.1	383	39.1	248	25.3	744	75.9
40	100	308	37.2	660	67	432	44	1232	126.7	4000	3000	≤30	15000

Model	Speed ratio	Enter the rated torque at 2000r/min		Allowed peak torque at start stop		The allowable maximum of the average load torque		Maximum torque is allowed in an instant		Allow the maximum speed to be entered	Average input speed is allowed	Back gap	design life
		NM	kgfm	NM	kgfm	NM	kgfm	NM	kgfm	r / min	r / min	Arc sec	Hour
14	50	7	0.7	23	2.3	9	0.9	46	4.7	14000	8500	≤20	15000
	80	10	1	30	3.1	14	1.4	61	6.2
	100	10	1	36	3.7	14	1.4	70	7.2
17	50	21	2.1	44	4.5	34	3.4	91	9	10000	7300	≤20	20000
	80	29	2.9	56	5.7	35	3.6	113	12
	100	31	3.2	70	7.2	51	5.2	143	15
20	50	33	3.3	73	7.4	44	4.5	127	13	10000	6500	≤20	20000
	80	44	4.5	96	9.8	61	6.2	165	17
	100	52	5.3	107	10.9	64	6.5	191	20
	120	52	5.3	113	11.5	64	6.5	191	20
	160	52	5.3	120	12.2	64	6.5	191	20
25	50	51	5.2	127	13	72	7.3	242	25	7500	5600	≤20	20000
	80	82	8.4	178	18	113	12	332	34
	100	87	8.9	204	21	140	14	369	38
	120	87	8.9	217	22	140	14	395	40
32	50	99	10	281	29	140	14	497	51	7000	4800	≤20	20000
	80	153	16	395	40	217	22	738	75
	100	178	18	433	44	281	29	841	86
40	100	345	35	738	75	484	49	1400	143	5600	4000	≤20	20000
