Factory Price 50n 500n 2000n Multi Axis Load Cell Triaxial Load Cell for Force Monitoring
HomeHome > Products > TRIAXIAL ASSEMBLY > Factory Price 50n 500n 2000n Multi Axis Load Cell Triaxial Load Cell for Force Monitoring
PRODUCT CATEGORIES
LATEST PRODUCTS
Factory Price 50n 500n 2000n Multi Axis Load Cell Triaxial Load Cell for Force Monitoring

Factory Price 50n 500n 2000n Multi Axis Load Cell Triaxial Load Cell for Force Monitoring

Package Size 26.00cm * 17.00cm * 8.00cm Package Gross Weight 2.000kg
Send to us
Basic Info.
Model NO. FA704
Output Signal Type Digital Type
Feature Low Temperature Resistant
Production Process Integration
Material Stainless Steel
IP Rating IP65
Certification CE
Customized Customized
Transport Package Cartons, Sponges, Wooden Box Pallets
Specification 25*18*7cm
Trademark Fibos
Origin China
HS Code 9031809090
Production Capacity 1000PCS/Month
Packaging & Delivery
Package Size 26.00cm * 17.00cm * 8.00cm Package Gross Weight 2.000kg
Product Description

Multi-axis Force Sensor-FA70 Series

FeaturesTriaxial force sensor multiple range load cell FA704C can measure forces in three vertical axes at the same time. The 3-axis load cell is available in a capacity range from 50N to 5000N for all three axes. The three dimensional force sensor is based on the strain transducer and adopts the resistance strain transducer principle. The 30mm height of this multi axis load cell allows it to be used in many situations* High precision* Strong resistance to partial load* Long-term stabilityApplications* Industrial test benches* Force monitoring* Force control in robotics

Please contact Estee for more suitable products and details→

Specifications

Technique

Specifications

Technique

Capacity(N)

X:50/100/200/500/1000/2000/5000;Y:50/100/200/500/1000/2000/5000;Z:50/100/200/500/1000/2000/5000.

Insulation

≥5000MΩ/100VDC

Rated output

≈1.0mV/V

Recommended excitation

5~12V

Zero balance

±2%F.S.

Maximum excitation

15V

Non-linearity

0.1%F.S.

Compensated temp range

-10~40ºC

Hysteresis

0.1%F.S.

Operation temp range

-20~75ºC

Repeatability

0.1%F.S.

Safe overload

150%F.S.

Interference error

0.3%F.S.

Ultimate overload

300%F.S.

Temp.effect on output

0.1%F.S./10ºC

Cable size

Φ5×3000mm

Temp.effect on zero

0.1%F.S./10ºC

Ultimate overload

300%F.S.

Input impedance

785±20Ω

Cable size

Φ3.2×3000mm

Output impedance

700±10Ω

The core team of Fibos has 20 years of experience in the design and production of advanced sensors in Germany. We continuously develop and produce: precision micro and small force sensors, dynamic and static torque sensors, six-dimensional force, three-dimensional force, multi-dimensional force sensors, load cells, custom ring force sensors, thread force sensors, thread preload force sensors, sensors for robots, tension series and various non-standard force sensors, etc. The company produces pressure force sensors: accurate measurement, low height, small deformation, high precision, good stability, fast response, easy installation, long life, complete specifications and sizes, not only for push and pull meters, hopper scales, a variety of industrial weighing systems, automotive press assembly, automated assembly, 3C product testing; also used in new energy product assembly, medical testing, textiles, robotics, mold assembly, wind energy, nuclear power and ships, etc. The product dynamic response frequency is high, also can accept custom specifications. In the application of high-frequency loud, fatigue strength after the test, life use up to 100 million times, suitable for all kinds of aircraft, automotive testing occasions.
